Symbologies#

Reverse Symbologies#

../../media/00161.png — Enable#

../../media/00160.png — * Disable#

EAN-8#

Enable/Disable#

../../media/00370.png — Disable#

../../media/00371.png — * Enable#

Transmit Check Character#

../../media/00570.png — Disable#

../../media/00571.png — * Enable#

Transmit System Characters#

../../media/00560.png — Disable#

../../media/00561.png — * Enable#

Add-On Code#

../../media/00550.png — * Disable#

../../media/00551.png — Enable 2-Digit Add-On Code#

../../media/00552.png — Enable 5-Digit Add-On Code#

../../media/00553.png — Enable 2-Digit And 5-Digit Additional Codes#

../../media/02611.png — Force Enable#

Note

Disable:When the scanner scans a barcode with an additional code, it decodes the barcode and ignores the additional code. The scanner can also decode barcodes without the additional code.
Force Enable:Scanner only decodes mixed barcodes with additional codes.

EAN-13#

Enable/Disable#

../../media/00360.png — Disable#

../../media/00361.png — * Enable#

UPC/EAN Multiple Verification#

../../media/00540.png — * Disable#

../../media/00541.png — Enable#

UPC/EAN Security Level#

../../media/00510.png — * 0#

../../media/00511.png — 1#

Transmit Check Character#

../../media/00460.png — Disable#

../../media/00461.png — * Enable#

Transmit System Characters#

../../media/00440.png — Disable#

../../media/00441.png — * Enable#

Add-On Code#

../../media/00550.png — * Disable#

../../media/00551.png — Enable 2-Digit Add-On Code#

../../media/00552.png — Enable 5-Digit Add-On Code#

../../media/00553.png — Enable 2-Digit And 5-Digit Additional Codes#

../../media/02611.png — Force Enable#

Note

Disable:When the scanner scans a barcode with an additional code, it decodes the barcode and ignores the additional code. The scanner can also decode barcodes without the additional code.
Force Enable:Scanner only decodes mixed barcodes with additional codes.

EAN-13 To ISBN#

ISBN is a book code, which normally outputs 13 digits. When the EAN-13 to ISBN conversion is turned on, the output is a 10-digit ISBN code.

../../media/00480.png — * Disable#

../../media/00481.png — Enable#

EAN-13 To ISSN#

ISSN is a magazine code, which normally outputs 13 digits. When the EAN-13 to ISBN conversion is turned on, the output is a 10-digit ISSN code.

../../media/01500.png — * Disable#

../../media/01501.png — Enable#

UPC-A#

Enable/Disable#

../../media/00340.png — Disable#

../../media/00341.png — * Enable#

Transmit Check Character#

../../media/00420.png — Disable#

../../media/00421.png — * Enable#

Transmit System Characters#

../../media/00400.png — Disable#

../../media/00401.png — * Enable#

Add-On Code#

../../media/00550.png — * Disable#

../../media/00551.png — Enable 2-Digit Add-On Code#

../../media/00552.png — Enable 5-Digit Add-On Code#

../../media/00553.png — Enable 2-Digit And 5-Digit Additional Codes#

../../media/02611.png — Force Enable#

Note

Disable:When the scanner scans a barcode with an additional code, it decodes the barcode and ignores the additional code. The scanner can also decode barcodes without the additional code.
Force Enable:Scanner only decodes mixed barcodes with additional codes.

UPC-A To EAN-13#

../../media/00390.png — * Disable#

../../media/00391.png — Enable#

UPC-E#

Enable/Disable#

../../media/00350.png — Disable#

../../media/00351.png — * Enable#

Transmit Check Character#

../../media/00430.png — Disable#

../../media/00431.png — * Enable#

Add-On Code#

../../media/00550.png — * Disable#

../../media/00551.png — Enable 2-Digit Add-On Code#

../../media/00552.png — Enable 5-Digit Add-On Code#

../../media/00553.png — Enable 2-Digit And 5-Digit Additional Codes#

../../media/02611.png — Force Enable#

Note

Disable:When the scanner scans a barcode with an additional code, it decodes the barcode and ignores the additional code. The scanner can also decode barcodes without the additional code.
Force Enable:Scanner only decodes mixed barcodes with additional codes.

UPC-E To UPC-A#

../../media/00380.png — * Disable#

../../media/00381.png — Enable#

Codabar#

Enable/Disable#

../../media/00850.png — Disable#

../../media/00851.png — * Enable#

Start And Stop Characters#

../../media/00860.png — * Disable#

../../media/00861.png — Enable#

Code 11#

Enable/Disable#

../../media/01260.png — Disable#

../../media/01261.png — * Enable#

Code 39#

Enable/Disable#

../../media/00220.png — Disable#

../../media/00221.png — * Enable#

Transmit Check Character#

../../media/00250.png — Disable#

../../media/00251.png — * Enable#

MOD43 Check#

../../media/00240.png — * Disable#

../../media/00241.png — Enable#

Multiple Verification#

../../media/00330.png — * Disable#

../../media/00331.png — Enable#

Start And Stop Characters#

The barcode data is preceded and followed by a “*” character as the start and stop characters. You can set whether to transmit the start and stop characters together with the barcode data after the barcode is read successfully.

../../media/00280.png — * Disable#

../../media/00281.png — Enable#

Full ASCII Support#

../../media/00230.png — * Disable#

../../media/00231.png — Enable#

Code 32 Setting#

../../media/01950.png — * Disable#

../../media/01951.png — Enable#

Code32 Prefix A#

../../media/01960.png — * Disable#

../../media/01961.png — Enable#

Set Minimum Length#

../../media/003201.png — Set Minimum Length to 1#

../../media/003202.png — * Set Minimum Length to 2#

Code 93#

Enable/Disable#

../../media/00620.png — Disable#

../../media/00621.png — * Enable#

Multiple Verification#

../../media/00680.png — * Disable#

../../media/00681.png — Enable#

Code 128#

Enable/Disable#

../../media/00690.png — Disable#

../../media/00691.png — * Enable#

Multiple Verification#

../../media/00840.png — * Disable#

../../media/00841.png — Enable#

Brazilian Bank Code#

../../media/08000.png — * Disable#

../../media/08001.png — Enable#

GS1 DataBar Limited（RSS Limited）#

Enable/Disable#

../../media/01770.png — * Disable#

../../media/01771.png — Enable#

GS1 DataBar Omnidirectional（RSS Omnidirectional）#

Enable/Disable#

../../media/01670.png — * Disable#

../../media/01671.png — Enable#

GS1 DataBar Expanded (RSS Expanded)#

Enable/Disable#

../../media/01870.png — * Disable#

../../media/01871.png — Enable#

Interleaved 2 of 5#

Enable/Disable#

../../media/00960.png — Disable#

../../media/00961.png — * Enable#

Multiple Verification#

../../media/01050.png — * Disable#

../../media/01051.png — Enable#

Set Minimum Length To 4#

../../media/009704.png — Set Minimum Length To 4#

Brazilian Bank Code#

../../media/01000.png — * Disable#

../../media/01001.png — Enable#

Industrial 2 of 5#

Enable/Disable#

../../media/01060.png — Disable#

../../media/01061.png — * Enable#

Set Minimum Length To 3#

../../media/010703.png — Set Minimum Length To 3#

Matrix 2 of 5#

Enable/Disable#

../../media/01460.png — * Disable#

../../media/01461.png — Enable#

Set Minimum Length To 2#

../../media/010703.png — Set Minimum Length To 2#

China Post#

Enable/Disable#

../../media/01570.png — * Disable#

../../media/01571.png — Enable#

MSI#

Enable/Disable#

../../media/01150.png — * Disable#

../../media/01151.png — Enable#

Transmit Check Character#

../../media/01350.png — * Disable#

../../media/01351.png — Enable#

Multiple Verification#

../../media/01250.png — * Disable#

../../media/01251.png — Enable#

Set Minimum Length To 3#

../../media/011903.png — Set Minimum Length To 3#

Plessey/Telepen#

Enable/Disable#

../../media/01160.png — * Disable#

../../media/01161.png — Enable#

Set Minimum Length To 3#

../../media/011903.png — Set Minimum Length To 3#
